C.7.4 Old Status Commands
Configuration Status
Configuration Status:
Confirmation:
ATT_yy.yy'cr'
AMP_nnn'cr'
TX_nnn'cr'
ONL_nnn'cr'
RED_xx_y'cr'
AFR_nnn'cr'
Where:
Attenuator
Amplifier – On/Off
Transmit – On/Off
Online – On/Off
See Note.
Auto Flt Recovery – On/Off
Notes:
1.
If Redundancy is Off, xx_y = Off, else if Redundancy is On
the xx field indicates the KPA designation, either BU
(Backup) 01 or 02.
2.
If xx is 01 or 02 then the y field indicates the Auto/Manual
status, either 'A' if Auto or 'M' if manual.
3.
If xx field is BU, the y field indicates the priority KPA, either 1
if KPA #1 is high priority or 2 if KPA #2 is high priority.
4.
For 1:1 systems priority is always #1.
Maintenance Status
Maintenance Status:
Confirmation:
V+28_xx.x'cr'
V+12xx.x'cr'
V-12_xx.x'cr'
V+5_x.x'cr'
V–5_x.x'cr'
V+9_1_xx.x'cr'
V+9_2_xx.x'cr'
TEMP_xx'cr'
FPWR_xx.x'cr'
RPWR_xx.x'cr''lf']
Where:
+28 VDC Supply
+12 VDC Supply
–12 VDC Supply
+5 VDC Supply
–5 VDC Supply
9 VDC Supply #1
9 VDC Supply #2
Temperature
RF Forward Power (dBm)
RF Reflected Power (dBm)
FET Status
KPA-020IN
FET Status:
Confirmation:
FET1_xxx'cr'
FET2_xxx'cr'
FET3_xxx'cr'
FET4_xxx'cr'
FET5_xxx'cr'
FET6_xxx'cr'
FET7_xxx'cr'
FET8_xxx'cr'
FET9_xxx'cr''lf']
Where:
FET1 current in mA
FET2 current in mA
FET3 current in amps
FET4 current in amps
FET5 current in amps
FET6 current in amps
FET7 current in amps
FET8 current in amps
FET9 current in amps
