KPA Ku-Band Indoor Solid-State Power Amplifier
Revision 1
Connectors and Pinouts
MN/KPA.IOM
3–3
KPA-020IN Unit KPA-040/-080/-100 Units
3.2
RF Connections
3.2.1
J1 RF IN / Tx IN Connectors
Connector Type
Description
Direction
SMA RF
Signal
In
3.2.2
J2 RF OUT Connector
Connector Type
Description
Direction
WR75G Waveguide Flange
RF Signal
Out
