KPA Ku-Band Indoor Solid-State Power Amplifier
Revision 1
Appendix C
MN/KPA.IOM
C–26
Packed Maintenance
Status
Packed Maint Status:
Confirmation:
'lf']
Where:
aa = + 28 VDC supply, 100mV per count above 10.0V in Hex
bb = + 12 VDC supply scaled 100 mV per count in Hex
cc = - 12 VDC supply scaled 100mV per count in Hex
dd = + 5 VDC supply scaled –100mV per count in Hex
ee = - 5 VDC supply scaled –100mV per count in Hex
ff = + 9 VDC supply #1 scaled 100 mV per count in Hex
gg = + 9 VDC supply #2 scaled 100mV per count in Hex
hhh = Signed temperature in degrees C (-10 to +95)
iii = RF forward power, 0.1 dBm steps above 20.0 dBm in Hex
jjj = RF reverse power, 0.1 dBm steps above 15.0 dBm in Hex
Packed FET Status
KPA-020IN
Packed FET Status:
Confirmation:
Where:
aa = FET1 current in Hex, formular:
FET1 = (aa) mA
bb = FET2 current in Hex, formular:
FET2 = (aa) mA
cc = FET3 current in Hex, scaled 100mV
per count
dd = FET4 current in Hex, scaled 100mV
per count
ee = FET5 current in Hex, scaled 100mV
per count
ff = FET6 current in Hex, scaled 100mV
per count
gg = FET7 current in Hex, scaled 100mV
per count
hh = FET8 current in Hex, scaled 100mV
per count
ii = FET9 current in Hex, scaled 100mV
per count
Packed FET Status
KPA-040
Packed FET Status:
Confirmation:
llmmnn'cr''lf']
Where:
aa = FET1 current in Hex, formular:
FET1 = (aa * 3) mA
bb = FET2 current in Hex, scaled 100mV
per count
cc = FET3 current in Hex, scaled 100mV
per count
dd = FET4 current in Hex, scaled 100mV
per count
ee = FET5 current in Hex, scaled 100mV
per count
ff = FET6 current in Hex, scaled 100mV
per count
gg = FET7 current in Hex, scaled 100mV
per count
hh = FET8 current in Hex, scaled 100mV
per count
ii = FET9 current in Hex, scaled 100mV
per count
jj = FET10 current in Hex, scaled 100mV
per count
kk = FET11 current in Hex, scaled 100mV
per count
ll = FET12 current in Hex, scaled 100mV
per count
mm = FET13 current in Hex, scaled 100mV per count
nn = FET14 current in Hex, scaled 100mV
per count
