ESC specific registers (0x0E00:0x0EFF)
II-76 Slave Controller – Register Description
3.50 ESC specific registers (0x0E00:0x0EFF)
3.50.1 Power-On Values ET1200
Table 130: Register Power-On Values ET1200 (0x0E00)
ESC20 ET1100 ET1200 IP Core
Bit Description ECAT PDI Reset Value
1:0 Chip mode (MODE):
00: Port 0: EBUS, Port 1: EBUS, 18 bit PDI
01: Reserved
10: Port 0: MII, Port 1: EBUS, 8 bit PDI
11: Port 0: EBUS, Port 1: MII, 8 bit PDI r/- r/- Depends on Hardware
configuration
3:2 CPU clock output (CLK_MODE):
00: Off
– PDI[7] available as PDI port
01: PDI[7] = 25MHz
10: PDI[7] = 20MHz
11: PDI[7] = 10MHz
r/- r/-
5:4 TX signal shift (C25_SHI):
00: MII TX signals shifted by 0°
01: MII TX signals shifted by 90°
10: MII TX signals shifted by 180°
11: MII TX signals shifted by 270° r/- r/-
6 CLK25 Output Enable (C25_ENA):
0:
Disabled – PDI[6] available as PDI port
1: Enabled – PDI[6] = 25MHz (OSC)
NOTE: Only used in Chip mode 10 and 11
r/- r/-
7 PHY Address Offset (PHYAD_OFF):
0:
No PHY address offset
1: PHY address offset is 16
r/- r/-
