ECAT Event Mask (0x0200:0x0201)
Slave Controller – Register Description II-37
3.29 ECAT Event Mask (0x0200:0x0201)
Table 46: Register ECAT Event Mask (0x0200:0x0201)
ESC20 ET1100 ET1200 IP Core
write
config.
V2.4.0/
V2.04a
writable
Bit Description ECAT PDI Reset Value
15:0 ECAT Event masking of the ECAT Event
Request Events for mapping into ECAT event
field of EtherCAT frames:
0:
Corresponding ECAT Event Request
register bit is not mapped
1: Corresponding ECAT Event Request
register bit is mapped
r/w r/- 0
3.30 PDI AL Event Mask (0x0204:0x0207)
Table 47: Register PDI AL Event Mask (0x0204:0x0207)
ESC20 ET1100 ET1200 IP Core
write
config.
Bit Description ECAT PDI Reset Value
31:0 AL Event masking of the AL Event Request
register Events for mapping to PDI IRQ
signal:
0:
Corresponding AL Event Request
register bit is not mapped
1: Corresponding AL Event Request
register bit is mapped
r/- r/w 0x00FF:0xFF0F
