Watchdog Divider (0x0400:0x0401)
II-44 Slave Controller – Register Description
3.39 Watchdog Divider (0x0400:0x0401)
Table 57: Register Watchdog Divider (0x0400:0x0401)
ESC20 ET1100 ET1200 IP Core
write
config.
Bit Description ECAT PDI Reset Value
15:0 Watchdog divider: Number of 25 MHz tics
(minus 2) that represents the basic watchdog
increment. (Default value is 100µs = 2498) r/w r/- 0x09C2
3.40 Watchdog Time PDI (0x0410:0x0411)
Table 58: Register Watchdog Time PDI (0x0410:0x0411)
ESC20 ET1100 ET1200 IP Core
Bit Description ECAT PDI Reset Value
15:0 Watchdog Time PDI: number or basic
watchdog increments
(Default value with Watchdog divider 100µs
means 100ms Watchdog) r/w r/- 0x03E8
Watchdog is disabled if Watchdog time is set to 0x0000. Watchdog is restarted with every PDI access.
3.41 Watchdog Time Process Data (0x0420:0x0421)
Table 59: Register Watchdog Time Process Data (0x0420:0x0421)
ESC20 ET1100 ET1200 IP Core
Bit Description ECAT PDI Reset Value
15:0 Watchdog Time Process Data: number of
basic watchdog increments
(Default value with Watchdog divider 100µs
means 100ms Watchdog) r/w r/- 0x03E8
There is one Watchdog for all SyncManagers. Watchdog is disabled if Watchdog time is set to
0x0000. Watchdog is restarted with every write access to SyncManagers with Watchdog Trigger
Enable Bit set.
