Distributed Clocks (0x0900:0x09FF)
II-70 Slave Controller – Register Description
Table 115: Register Start Time Cyclic Operation (0x0990:0x0993 [0x0990:0x0997])
ESC20 ET1100 ET1200 IP Core
[63:32] [63:32]
config.
Bit Description ECAT PDI Reset Value
63:0 Write: Start time (System time) of cyclic
operation in ns
Read: System time of next SYNC0 pulse in
ns r/(w) r/(w) 0
NOTE: Write to this register depends upon setting of 0x0980.0. Only writable if 0x0981.0=0.
Auto-activation (0x0981.3=1): upper 32 bits are automatically extended if only lower 32 bits are written within one
frame.
Table 116: Register Next SYNC1 Pulse (0x0998:0x099B [0x0998:0x099F])
ESC20 ET1100 ET1200 IP Core
[63:32] [63:32]
config.
Bit Description ECAT PDI Reset Value
63:0 System time of next SYNC1 pulse in ns r/- r/- 0
Table 117: Register SYNC0 Cycle Time (0x09A0:0x09A3)
ESC20 ET1100 ET1200 IP Core
Bit Description ECAT PDI Reset Value
31:0 Time between two consecutive SYNC0
pulses in ns.
0:
Single shot mode, generate only one
SYNC0 pulse.
r/(w) r/(w) 0
NOTE: Write to this register depends upon setting of 0x0980.0.
Table 118: Register SYNC1 Cycle Time (0x09A4:0x09A7)
ESC20 ET1100 ET1200 IP Core
Bit Description ECAT PDI Reset Value
31:0 Time between SYNC1 pulses and SYNC0
pulse in ns r/(w) r/(w) 0
NOTE: Write to this register depends upon setting of 0x0980.0.
