Controls, LEDs, and Connectors
MVME8100 / MVME8110 Installation and Use (6806800P25G) 65
7 GND 39 PERR
8 NC 40 GND
9 NC 41 +3.3V
10 NC 42 SERR
11 BUSMODE2
(Pulled UP) 43 CBE1
12 +3.3V 44 GND
13 PCI RESET 45 AD 14
14 BUSMODE3
(PULLED DWN) 46 AD 13
15 +3.3V 47 M66EN
16 BUSMODE4
(PULLED DWN) 48 AD 10
17 NC 49 AD 8
18 GND 50 +3.3V
19 AD 30 51 AD 7
20 AD 29 52 REQB
21 GND 53 +3.3V
22 AD 26 54 GNTB
23 AD 24 55 NC
24 +3.3V 56 GND
25 IDSEL 57 NC
26 AD 23 58 EREADY
27 +3.3V 59 GND
28 AD 28 60 RSTOUT
29 AD 18 61 ACK64
30 GND 62 +3.3V
31 AD 16 63 GND
Table 3-10 PMC J12/J22 Connector (continued)
Pin Name Signal Description Pin Name Signal Description
