Hardware Preparation and Installation

MVME8100 / MVME8110 Installation and Use (6806800P25G)

35

Prior to installing PMC modules on the MVME8100 / MVME8110 baseboard, ensure that all
switches that are user configurable are set properly. To do this, refer to

Figure 2-1

or the board

itself, for the location of specific switches and set the switches according to the following
descriptions.

Figure 2-1

Switch Locations (ENP1 board)

S5 Switch

S2 Switch

S3 Switch

S4 Switch
