Introduction
MVME8100 / MVME8110 Installation and Use (6806800P25G) 21
PCI Express  One 8X Port to PMC/XMC Site 1
 One 4X Port to PMC/XMC Site 2
USB  One USB 2.0 for front panel I/O
 Two USBs 2.0 for backplane RTM I/O
Ethernet  One 10/100/1000BASE-T Ethernet port to front panel (only in air
cooled variant)
 Two 10/100/1000BASE-T Ethernet channels to P2 / RTM
Serial Ports  One RS232/422/485 console port to front panel or P2 / RTM
 Up to 4 RS232/422/485 COM ports to P2/ RTM
VME Bus VME64x and 2eSST
Timers  Eight 32-bit timers in CPU
 Watchdog timer in CPU
PMC/XMC Two PMC/XMC sites with 64-bit PMCIO on Site 1
SATA SSD Option for one 2.5 inch SATA drive (PMC/XMC Site 2)
GPIO Interface Two GPIOs to RTM
Form Factor  Standard 6U, one slot
 Support 0.8, and 0.85 inch slot chassis
 Support heat frame on both sides for Conduction cooled board
Miscellaneous  One front panel RESET Switch
 LED front panel status indicators: four user/fail/ready LEDs
 Planar status indicators
 Boundary scan support
Software Support  VxWorks OS support
 Linux OS supports 32 bit
RTM Compatible with RTM (assembly # 0106852****)
Table 1-2 Features List of MVME8110 (continued)
Function Features
