Introduction
MVME8100 / MVME8110 Installation and Use (6806800P25G) 26
1.3 Mechanical Data
The MVME8100 is a full 6U board with added mounting holes to support an ENP4 board
variant. The MVME8100 / MVME8110 will occupy a single VME card slot.
Table 1-4 provides details on the board’s mechanical data.
1.4 Ordering Information
When ordering board variants or board accessories, use the order numbers given in the
following tables.
1.4.1 Supported Board Models
Table 1-4 Mechanical Data
Characteristic Value
Height 233.44 mm (9.2inches)
Depth 160.0 mm (6.3 inches)
Front Panel Height 261.8 mm (10.3 inches)
Width 19.8 mm (0.8 inches)
Maximum Component Height 14.8 mm (0.58 inches)
Weight (estimated) 0.58 Kg (ENP1)
0.90 Kg (ENP4)
Table 1-5 Board Variants
Marketing # Processor
MVME8100-202200401E P5020 2.0GHz 28W, 4GB DDR3, VXS, 2 PMC/XMC, IEEE, ENP1
MVME8100-202200401S P5020 2.0GHz 28W, 4GB DDR3, VXS, 2 PMC/XMC, SCANBE, ENP1
MVME8100-202200404 P5020 1.8GHz 27W, 4GB DDR3, VXS, 2 PMC/XMC, ENP4
MVME8110-01E P5010 1.2GHZ, 2GB DDR3, 2PMC/XMC, ENP1 IEEE
