Hardware Preparation and Installation
MVME8100 / MVME8110 Installation and Use (6806800P25G) 37
2.4.1 Configuration Switches
The board provides the following configuration switches:
 S2 Switch
 S3 Switch
 S4 Switch
 S5 Switch
 Reset/Abort Switch
2.4.1.1 S2 Switch
The Switch Bank S2 provides watchdog control, serial port configuration and P0 fabric
selection.
Table 2-5 S2 Switch Settings
Position Default Description
1 OFF OFF - Watchdog Disabled
ON - Watchdog Enabled
2 OFF OFF - Serial Console Port to Front Panel
ON - Serial Console Port to P2/RTM panel
3 OFF OFF - P2 Serial Port 0 is RS232
ON - P2 Serial Port 0 is RS422/485
4 OFF OFF - P2 Serial Port 1 is RS232
ON - P2 Serial Port 1 is RS422/485
5 OFF OFF - P2 Serial Port 2 is RS232
ON - P2 Serial Port 2 is RS422/485
6 OFF OFF - P2 Serial Port 3 is RS232
ON - P2 Serial Port 3 is RS422/485
7 OFF OFF - Front Panel console Port is RS232
ON - Front Panel console Port is RS422/485
8 OFF OFF - Select SRIO for P0 Backplane Fabric (applicable to MVME8100 only)
ON - Select PCIe for P0 Backplane Fabric (applicable to MVME8100 only)
