Controls, LEDs, and Connectors
MVME8100 / MVME8110 Installation and Use (6806800P25G) 64
15 GND 47 AD 12
16 GNT A 48 AD 11
17 REQ A 49 AD 9
18 +5V 50 +5V
19 +3.3V 51 GND
20 AD 31 52 CBE0
21 AD 28 53 AD 6
22 AD 27 54 AD 5
23 AD 25 55 AD 4
24 GND 56 GND
25 GND 57 +3.3V
26 CBE3 58 AD 3
27 AD 22 59 AD 2
28 AD 21 60 AD 1
29 AD 19 61 AD 0
30 +5V 62 +5V
31 +3.3V 63 GND
32 AD 17 64 REQ64
Table 3-10 PMC J12/J22 Connector
Pin Name Signal Description Pin Name Signal Description
1 +12V 33 GND
2 JTAG TRST 34 IDSELB
3 JTAG TMS 35 TRDY
4 JTAG TDO 36 +3.3V
5 JTAG TDI 37 GND
6 GND 38 STOP
Table 3-9 PMC J11/J21 Connector (continued)
Pin Name Signal Description Pin Name Signal Description
