Hardware Preparation and Installation
MVME8100 / MVME8110 Installation and Use (6806800P25G) 41
2.4.1.5 Reset /Abort Switch
A dual function switch can be found in the front panel. This switch can function either as a Reset
or Abort button. If the button is pressed for less than 3 seconds, the CPLD will generate an abort
interrupt to the P5020 / P5010 processor. If the button is pressed for more than 3 seconds, the
CPLD will generate a board hard reset. If the board is configured as System Controller, the
backplane VME SYSRESET signal is also asserted during a board hard reset.
2.5 Installing Accessories
This section describes the procedures for installing the RTM of MVME8100/ MVME8110, PMCs,
and the XMCspan on the baseboard.
2.5.1 Rear Transition Module
The RTM of MVME8100/ MVME8110 does not support hot swap, You must remove power to
the system before installing the module. Before installing the transition module, you may need
to manually configure the RTM switches and install a PMC I/O Module (PIM).
Damage of Circuits
Electrostatic discharge and incorrect installation and removal can damage circuits or
shorten their life.
Before touching the board or electronic components, make sure that you are working in an
ESD-safe environment.
Product Damage
Only use injector handles for board insertion to avoid damage to the front panel and/or PCB.
Deformation of the front panel can cause an electrical short or other board malfunction.
Board Malfunction
Switches marked as “reserved” might carry production-related functions and can cause the
board to malfunction if their setting is changed.
Do not change settings of switches marked as “reserved”. The setting of switches which are
not marked as “reserved” has to be checked and changed before board installation.
