Hardware Preparation and Installation
MVME8100 / MVME8110 Installation and Use (6806800P25G) 48
5. Remove PMC/XMC bracket and mounting posts from site 2 as shown in step 4 of Figure 2-
4.
6. Attach SATA drive assembly with adapter board and mounting brackets to MVME8100 /
MVME8110 board at PMC/XMC site 2 as shown in step 5 of Figure 2-4. Make sure that the
SATA adapter connector is fully mated with the board SATA connector.
7. Secure SATA drive assembly to board using four screws inserted from the bottom side of
the board as shown in step 5 of Figure 2-4.
2.6 Installing and Removing the Board
This section describes the recommended procedure for installing the MVME8100 /
MVME8110 board in a chassis. The MVME8100 / MVME8110 does not support hot swap, you
must remove power to the slot or system before installing the module. Before installing the
MVME8100 / MVME8110, ensure that the serial ports and switches are properly configured.
Installation and Removal Procedure
Before you install your module, please read all cautions, warnings and instructions presented
in this section.
Damage of Circuits
Electrostatic discharge and incorrect installation and removal can damage circuits or
shorten their life.
Before touching the board or electronic components, make sure that you are working in an
ESD-safe environment.
Product Damage
Only use injector handles for board insertion to avoid damage to the front panel and/or PCB.
Deformation of the front panel can cause an electrical short or other board malfunction.
