2-6
2 • Getting to Know Your System
SV62261 Rev. F
Parts of the Machine - DM475
1
2
3
4
5
10
16
11
13
15
(shown with optional
weighing platform)
14
8
12
Item Part Description
1 Feeder/WOW
Cover Opens up to allow access to the WOW deck and
two clearance levers (items #16 and #17)
2 Seal/No Seal
Lever Allows you to turn envelope sealing on and off
3 Sealing Fluid
Level Indicator Allows you to see how much sealing fluid is left in
the tank (red band indicates low level)
4 Tape Feeder Holds and feeds tape strips for printing
5 Weighing
Platform
(optional) Allows you to weigh a mail piece so your system
can calculate postage based on the service
selected
6 Ink Access
Cover (under
optional scale) Opens up to allow replacement of the ink
cartridge (see Chapter 12, Maintenance)
7
6
9
17
(shown with
cover open)
