2-5
2 • Getting to Know Your System
SV62261 Rev. F
Parts of the Machine - DM400c
Item Part Description
1 Feeder Access
Cover Opens up to allow access to the moistener bottle
2 Seal/No Seal
Lever Allows you to turn envelope sealing on and off
3 Ink Access
Cover Opens up to allow replacement of the ink
cartridge (see Chapter 12, Maintenance)
4 Weighing
Platform
(optional) Allows you to weigh a mail piece (your system
can then calculate postage based on the service
selected)
5 Ink Waste Tank
(in tray under
printer section) Collects ink waste
6 Control Panel Allows you to enter and set up information on
your machine (see page 2-8 for details)
7 Clearance
Lever (two
position) Home - printer rollers engaged for processing
mail (normal)
Released - printer rollers disengaged; lower
portion of printer deck drops down so you can
clear a stalled mail piece
i
NOTE: The machine won't process mail
when the lever is left in the released position.
8 Printer Deck Supports your mail piece as it passes un der the
printer mechanism
9 Tape Feeder Holds and feeds tape strips for printing
10 Moistener Applies sealing fluid to the envelope flap (you
can seal envelopes or leave them unsealed,
depending on the position of Seal/No Seal lever)
11 Side Guide Reduces the skewing of pieces of mail as you
feed them into the feeder.
12 Feeder Deck Supports your mail piece as it waits to be fed into
the printer mechanism.
13 Stacker Tray
Storage Slot Allows you store the Quick Reference Guide, CD,
etc. for easy access.
14 Stacker Tray Allows the neat stacking of finished mail pieces
