Page 67
PhoIntval 4 (S) The interval of auto photo (Timing-PG).
Cruise thr 50%
Throttle reference quantity when switch to the
navigation working mode.
PG DELAY 1200 (ms)
The interval time between output the camera shutter
and completely save the POS data of the photo
ASP 120 The reference value of the airspeed sensor calibration.
Auto Take Off Parameters
Name Parameter Instruction
TakeOff pitch 15° The minimum climb angle during auto takeoff.
TakeOffThrottle 95%
The maximum throttle quantity for using during
the auto takeoff
Configuration Of Auto Takeoff & Auto Landing Mode
Auto Landing Line
Note：The default altitude of open parachute is 50
meters when select the
―Parachute‖ Landing
mode .
Auto Takeoff Hands Throws
Configuration of RC
Remote Control Setting Instruction
SW2
Go Home
Note: SW2 have to maintain a NULL
position.
NULL
Path
RC Max Distance 4000 Meters
Note: This function activate when
autopilot system connect as
―OPTION1 (RC control mode)‖
Other Basic Configuration
Control Mode ―DDRC‖ Mode (Note: Matching to the ―OPTION2‖ connection )
Fail Save
Auto Return (Note: Setting only activate when autopilot system connect as
―OPTION2 —— ―DDRC‖ control mode)‖
Mixing Control Normal (AIL NAV)
Install Setting Arrow Front
