Page 49
3. Special Instruction For Navigation Working Mode
 The aircraft can not be control by Remote Control when work in navigation mode
except Fixed altitude & Heading lock Mode.
 The aircraft can be control by Remote Control when work in Fixed altitude & Heading
lock Mode except the throttle.
 When working in navigation mode, once the flight altitude descend to less than 12
meters, the throttle will shut down.
4. Auto Waypoint Photograph Setting
The ―Auto Take Photo Waypoint‖ function
can be set up i n page ―Param2‖in the tool bar on
GCS.
The
autopilot will activate the ―Auto Photo‖
when the aircraft arrive the start waypoint, and
turn off
the ― Auto Photo‖ when arrive the end
waypoint in the Path Navigation working mode.
For example: Parameters set as―Start‖: 2,―End‖: 4, the auto take photo function will
be activate at the waypoint which is number 2 and turn off at the waypoint which is
number 4.
 When the starting and the ending point set as “0”,it means that disable the
function of “Set Auto Take Photo Waypoint”.
 After finish the parameter setting, please click the “Save” button in page
“Param1” in the tool bar to save the setting.
5. Set Up Target Waypoints
( 1 ) Significance Of Setting Target Waypoint

Working in the path navigation mode. When the autopilot receive the command
about the setting target waypoint, the aircraft will fly immediately to the target waypoint
from the current position then execute the new routes (The new route start from target
waypoint to the ending waypoint) .
