7.2 Live Audio Settings
The Live Audio Settings window is used to adjust recording levels and monitor live audio.
Cycles through the available audio channels to monitor live audio. Select the channel to monitor by click-
ing on the channel name or use the
button to select a channel. To disable live monitoring, use the but-
ton to select the Stop Monitor option.
Reset Resets the volume and sensitivity levels for the selected live audio channel.
Close Window Closes the Live Audio Settings window.
The audio visualization graph provides a visual representation of the audio information currently being
recorded. Keep an eye on this graph while modifying audio sensitivity and live volume settings.
Sensitivity
Controls the sensitivity of the audio detection. Higher sensitivity will trigger audio recording at the slight-
est noise while lower sensitivity will only trigger audio recording with louder noise.
Live Volume Use the slide bar to adjust the live volume of the selected audio channel.
Capture Volume
Use the slide bar to adjust the live volume of the selected audio channel. (Only available on VIGIL Server
systems using a capture card.)
