C-PRO NANO RACK E C-PRO MICRO RACK APPLICATION MANUAL
Page 42
visibility
*1
HC24
Set the digital output position for the
throttling 2 of compr.4
0
0
6 (12)
n
CO-Hw
(12 if
expansion
is
enabled);
visibility
*1
HC31
Set the analogue output position that is
associated to the inverter of circuit 1’s
compressors
2
0
3
n
CO-Hw
The 2
nd
and 3
rd
outputs
need AO
expansion;
visible if
PG12 = 1
HC32
Set the analogue output position that is
associated to the inverter of circuit 2’’s
compressors
0
0
3
n
CO-Hw
The 2
nd
and 3
rd
outputs
need AO
expansion;
visible if
PG01 > 1
and
PG16 = 1
HF01
Set the digital output position for fan 1
Or
Set the inverter fan consent position for
circuit 1 (if circuit 1 inverter is enabled)
3
0
6 (12)
n
CO-Hw
HF02
Set the digital output position for fan 2
Or
Set the inverter fan consent position for
circuit 2 (if circuit 2 inverter is enabled)
4
0
6 (12)
n
CO-Hw
HF03
Set the digital output position for fan 3
Or
Set the inverter fan consent position for
circuit 3 (if circuit 3 inverter is enabled)
0
0
6 (12)
n
CO-Hw
HF04
Set the digital output position for fan 4
Or
Set the inverter fan consent position for
circuit 4 (if circuit 4 inverter is enabled)
0
0
6 (12)
n
CO-Hw
(13)
PWM1
Consent
(14)
PWM2
Consent
Visibility
*
2
HF31
Set the position of the analogue output
associated with fan inverter of circuit 1
1
0
3
n
CO-Hw
The 2
nd
and 3
rd
outputs
need AO
expansion;
visible if
PG42 = 1
HF32
Set the position of the analogue output
associated with fan inverter of circuit 2
0
0
3
n
CO-Hw
The 2
nd
and 3
rd
outputs
need AO
expansion;
visible if
PG01 > 1
and
PG42 = 1
and
PG30 = 0
HA01
Set the positions of the digital output
associated with the global alarm signal
6
0
6 (12)
n
CO-Hw
(12 if
expansion
is enabled)
HA11
Set the position of the digital output
0
0
6 (12)
n
CO-Hw
(12 if
expansion
