RocketLinx ES7510 User Guide: 2000544 Rev. B Power over Ethernet (CLI) - 149
Configuration Using the Command Line Interface (CLI)
PoE Budget Warning (%)
Set
Switch> enable
Switch# config term
Switch(config)# interface fa1
Switch(config-if)# poe budget
auto Auto mode
manual Manual mode
warning Warning water level
Switch(config-if)# poe budget warning
<0-100> 0 is disable, valid range is 1 to 100 percentage
Switch(config-if)# poe budget warning 60
PoE Schedule Weekday Hour
Enable Hour 1, 3, 5
and 10 to 23 on
Sunday
Switch> enable
Switch# config term
Switch(config)# interface fa1
Switch(config-if)# poe schedule
<0-6> Weekday: valid range 0-6 (0=Sun, 1=Mon..., 6=Sat)
Switch(config-if)# poe schedule 0 1,3,5,10-23
Disable Sunday
Schedule Switch(config-if)# no poe schedule 0
PoE Budget
Set
Switch(config)# poe
budget Configure the power budget of power over ethernet
pd-detect Configure PD status detection
Switch(config)# poe budget
<0-400> Power budget : 0 - 400 Watts
warning Warning water level
Switch(config)# poe budget 400
PoE PD Detect
Enable
Switch> enable
Switch# config term
Switch(config)# poe
disable Disables power over ethernet
enable Enables power over ethernet
budget Configure the power budget of power over ethernet
pd-detect Configure PD status detection
Switch(config)# poe pd-detect
disable Disable PD status detection
enable Enable PD status detection
A.B.C.D PD IP address
Switch(config)# poe pd-detect enable
Disable Switch(config)# poe pd_detect disable
PoE PD Detect Cycle Time
Ping 20 Sec, Re-
enable PoE Switch(config)# poe pd_detect 192.160.1.2 20
