Setting Items
I Camera Settings
. General Settings
Item IK-WB01A IK-WB11A
Camera Picture Size 160 x 120
320 x 240
640 x 480
320 x 240 ZOOM
160 x 1 2 0 ZOOM
1280 x 960
800 x 600
640 x 480
320 x 240
160 x 120
Picture Quality HIGH/MIDDLE/LOW HIGH/MIDDLE/LOW
Frame Rate HIGH/MIDDLE/LOW HIGH/MIDDLE/LOW
Installation Environment Desktop/Wall, Ceiling Desktop/Wall, Ceiling
AE Compensation -20 to 20 -20 to 20
Auto B/W ON/OFF ON/OFF
Shutter Speed AES,1/120,1/60,1/30,
1/20,1/15,1/8,1/4,1/2,1,
2,4
Auto Slow Shutter*' — ON/OFF
Auto Sensitivity Boost — ON/OFF
Sound Sensitivity HIGH/LOW HIGH/MIDDLE/LOW
■ 1: Auto-Slow shutter functions when the "shutter speed" is set "AES"
• Camera Picture Size :
Configures camera picture size. The bigger the size, the resolutions
becomes higher.
IK-WB'
Possible settings 1280 X960/800 X 600/640 Х480/
320 X 240/160x120
IK-WB01A
Possible settings : 640 x 480 / 320 x 240 / 160 x 120/
320 x 240 ZOOM/1 60x120 ZOOM
The 320 x 240 ZOOM/160x120 ZOOM settings enlarge the center
part of an image (640 x 480)and display it on the screen.
• Picture Quality:
Configures the quality of camera images. When the picture sizes are the
same, the file sizes change according to the each picture quality level.
HIGH
MIDDLE
LOW
^NOTE
Better picture quality, but the file size becomes bigger.
Standard quality and file size.
Lower picture quality, but the file size becomes smaller.
• The picture quality and the file size change depending on the
conditions of an object (splendor, resolution, movement).
• The smaller the file size, the network system will have less influence.
As a result, frame rate (next page) may become higher.
