Specifications
Model name IK-WB01A IK-WB11A
Image sensor 1/5-inch CCD 1/2-inch CCD
Effective Picture Element 350k pixel 1.45 megapixel
Focal length f=2.6mm f = 6.0 mm
Angle of view Horizontal: 58 ° , vertical: 45 ° , diagonal: 70 ° Horizontal: 56 ° , vertical: 44 ° , diagonal: 67 °
Maximum relative aperture F = 2.8 F = 1.4
Shutter speed AES AES, 1/120, 1/60, 1/30, 1/20, 1/15, 1/8, 1/4, 1/2, 1,2, 4, sec.
Minimum illumination 2 lx (Frame Rate HIGH)
0.7lx (Frame Rate LOW)
1 lx (Normal, Auto-Sensitivity Boost OFF)
0.03 lux (Slow shutter ON)
Pan 112° (-56° to 5i6° )
Tilt 54° (-49° to 5° )
Pan/tilt presets 10 positions
Alarm terminal Input X 1, Output X 1
Image size 640X480 320X240 160x120
320x240zoom 160xl20zoom
1280X960 800X600
640X480 320X240 160 x 120
Image compression method JPEG
Quality settings 3 levels
Maximum frame rate Max. 7.5 fps(640x480),
Max. 15 fps(320x240zoom, 160x120zoom)
Max. 7.5 fps(1280x960, 800x600, 640x480),
Max. 30 fps(320x240, 160x120)
Audio *1 Available (built-in microphone, PCM) Available (MIC IN, PCM)
Privacy mask feature Unavailable Available
Motion alarm feature Unavailable Available
Normal recording feature Unavailable Available
External storage media Unavailable SD memory card
Video output Unavailable Available *2
Mail notification feature Available
ND switching mechanism *3 None Available
Interface RJ-45 (10Base-T/100Base-TX), wireless LAN (IE EE802.11b)
Protocols TCP/IP, UDP/IP, HTTP, SMTP, DNS, DHCP, NTP, ARP, ICMP, syslog, DDNS RNCP
Power supply voltage 10V DC
Power consumption 8W
Operating ambient Temperature: 0t to +40t/
temperature/humidity Humidity: 80% or less
Storage temperature -20t to +60t
Weight Approx. 600 g (camera only) Approx. 650 g (camera only)
External dimensions 127 (W)X127 (H)X110 (D)mm (camera only)
Accessories AC adaptor (1), Power cord (1),
Wall attachment (for indoor use) (1),
Clamp filter(x2)
Screw set, Basic User's Guide,
Quick Start Guide,
LAN cable (Straight-through cable)(1)
AC adaptor (1), Power cord (1), Rear cover
(waterproof cover and wall attachment
holder for indoor and outdoor installation)(1).
Sun visor (for outdoor installation)(1),
Wall bracket(1), Screw set, Basic User's
Guide, Quick Start Guide, LAN cable
(Straight-through cable)(1)
*3:
The sound may not be clear depending on the conditions of the lines.
The image output is for checking the image during installation. Images
and sounds are not deliverd, and recording function will not work during
installation.
The ND filter makes possible to monitor either outdoor or indoor location
by controlling light intensity.
• Designes as specifications may change without prior notice for better
improvement.
