Toshiba IK-VR01A User Manual

Ik-vr01a

background image

INSTRUCTION MANUAL

CCD COLOR CAMERA

IK-VR01A

Please read this manual thoroughly before use, and keep it handy
for future reference.

TABLE OF CONTENTS

Important safeguards

1. Features & Description ................................................. 3
2. Cautions ........................................................................ 3
3. Components ................................................................. 3
4. Part Names & Functions ............................................... 4
5. Connections and Operations ........................................ 5
6. Installations ................................................................... 7
7. Line Lock Phase ........................................................... 12
8. Note on use and Installation ......................................... 12
9. In Case of Problems ..................................................... 13

10. Specifications ................................................................ 14

11. Exterior View ................................................................. 15

Record in space provided below the Model No. and
the Serial No. as found on the label on the bottom
of this unit.
Model. No. IK-VR01A Serial No.
Retain this information for future reference.
