Parallel Interface Specifications
Interface Connector
Pin Assignment
Printer Side: Amphenol FCN-685J036-L/X or equivalent
A shielded cable should be used.
Pin No.
Signal
Direction
Pin No.
Signal
Direction
1
DATA STROBE Input
19
0V(S.G.)
.
2
DATAI
Input
20
0V(S.G.)
-
3
DTAT2
Input
21
0V(S.G.)
-
4
DATA3
Input
22
0V(S.G.)
-
5
DATA 4
Input
23
0V(S.G.)
-
6
DATAS
Input
24
0V(S.G.)
-
7
DATA 6
Input
25
0V(S.G.)
-
8
DATA 7
Input
26
0V(S.G.)
-
9
DATAS
Input
27
0V(S.G.)
-
10
ACKNLG
Output
28
OV(S.G.)
-
11
BUSY
Output
29
0V(S.G.)
-
12
PE
Output
30
0V(S.G.)
-
13
SLCT
Output
31
IMPUT PRIME Input
14
AUTO FEED
Input
32
FAULT
Output
15
N.C.
-
33
N.C.
-
16
OV (S.G.)
-
34
N.C.
-
17
0V(S.G.)
-
35
N.C.
-
18
+5V
-
36
SLCT IN
Input
Kesident Fonts
The following bitmapped fonts are resident in the MFC.
Brougham 10 (12 point)
upright/normal
upright/bold
italic/normal
italic/bold
Brougham 12 (10 point)
upright/normal
upright/bold
italic/norml
italic/bold
Letter Gothic 16.66 (8.5 point) upright/normal
upright/bold
italic/normal
italic/bold
(Portrait and Landscape are available for the above.)
