CHAPTER 3: CONTROL PANEL OPERATION
Page 36 of 152 PR2: 05/09/12
Benchmark 1.5LN Low NOx Boiler
Operation and Maintenance Manual
OMM-0041_0D
GF-120
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 • Ph: 800-526-0288
3.6 CONFIGURATION MENU
The Configuration Menu shown in Table 3-4 permits adjustment of the Internal Setpoint (Setpt)
temperature regardless of whether the valid password has been entered. Setpt is required for
operation in the Constant Setpoint mode. The remaining options in this menu require the valid
password to be entered, prior to changing existing entries. This menu contains a number of
other configuration settings which may or may not be displayed, depending on the current
operating mode setting.
NOTE
The Configuration Menu settings shown in Table 3-4 are
Factory-Set in accordance with the requirements
specified for each individual order. Therefore, under
normal operating conditions, no changes will be required.
Table 3-4: Configuration Menu
Available Choices or Limits
Menu Item Display Minimum Maximum Default
Internal Setpt Lo Temp Limit Hi Temp Limit 130°F
Unit Type KC Boiler, KC Boiler LN,
BMK Boiler Std, BMK Boiler LN,
BMK Blr Std Dual, BMK Blr LN KC Water
Heater,
KC Wtr Heater LN,
Innovation WH
BMK Boiler LN
Unit Size 600 MBH, 750 MBH, 800 MBH 1000 MBH,
1060 MBH,
1500 MBH, 2000 MBH,
3000 MBH
1500 MBH
Fuel Type Natural Gas, Propane Natural Gas
Boiler Mode Constant Setpoint, Remote Setpoint,
Direct Drive, Combination
Outdoor Reset
Constant Setpoint
Available Choices or Limits
Menu Item Display Minimum Maximum Default
Remote Signal
(If Mode = Remote Setpoint, Direct
Drive or Combination)
4 – 20 mA/1 – 5V
0 -20 mA/0 – 5V
PWM Input (BMS)
Network
4 – 20 mA,
1-5V
Bldg Ref Temp (If Mode = Outdoor Reset) 40°F 230°F 70°F
Reset Ratio(If Mode = Outdoor Reset) 0.1 9.9 1.2
Outdoor Sensor Enabled or Disabled Disabled
System Start Tmp (If Outdoor Sensor-
Enabled)
30°F 100°F 60°F
Setpt Lo Limit 40°F Setpt Hi Limit 60°F
Setpt Hi Limit Setpt Lo Limit 195°F 195°F
Temp Hi Limit 40°F 210°F 195°F
Max Valve Position 40% 100% 100%
