USER MANUAL
AERCO/ProtoNode Gateway
OMM-0080_0D
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288 VD2:011712
1
GF-129
Equipment Point Name Name
Read
Only BACnet
Type:ID
N2 Type N2 ID
Lon SNVT
NAME
Lon SNVT Lon Direction
ModBus/Unit
Address
06-Over Temp Alarm unitstat_17

AV:176 data float 176 nvoEcsStat17 inc count (9) Output (non-polled) 30075/17
07-Flow Rate flowrate_17

AV:177 data float 177 nvoEcsFlow17 inc count (9) Output (non-polled) 30171/17
E Valve Addr 18
01-Cntl Output Signal boilerstate_18

AV:181 data float 181 nvoEcsState18 inc count (9) Output (non-polled) 18004/18
02-Setpoint effectsetpt_18

AV:182 data float 182 nvoEcsSetpt18 inc count (9) Output (non-polled) 18006/18
03-RmSetpt rmsetpt_18 AV:183 data float 183
nviEcsSetptRq
18
inc count (9) Input (non-polling) 40027/18
04-Outlet Temp
localsuptemp_1
8 
AV:184 data float 184
nvoEcsSupTmp
18
inc count (9) Output (non-polled) 18002/18
05-FBk Sensor Temp
localrettemp_1
8 
AV:185 data float 185
nvoEcsRetTmp
18
inc count (9) Output (non-polled) 18290/18
06-Over Temp Alarm unitstat_18

AV:186 data float 186 nvoEcsStat18 inc count (9) Output (non-polled) 18075/18
07-Flow Rate flowrate_18

AV:187 data float 187 nvoEcsFlow18 inc count (9) Output (non-polled) 18291/18
E Valve Addr 19
01-Cntl Output Signal boilerstate_19

AV:191 data float 191 nvoEcsState19 inc count (9) Output (non-polled) 30004/19
02-Setpoint effectsetpt_19

AV:192 data float 192 nvoEcsSetpt19 inc count (9) Output (non-polled) 30006/19
03-RmSetpt rmsetpt_19 AV:193 data float 193
nviEcsSetptRq
19
inc count (9) Input (non-polling) 40027/19
04-Outlet Temp
localsuptemp_1
9 
AV:194 data float 194
nvoEcsSupTmp
19
inc count (9) Output (non-polled) 30002/19
05-FBk Sensor Temp
localrettemp_1
9 
AV:195 data float 195
nvoEcsRetTmp
19
inc count (9) Output (non-polled) 30290/19
06-Over Temp Alarm unitstat_19

AV:196 data float 196 nvoEcsStat19 inc count (9) Output (non-polled) 30075/19
07-Flow Rate flowrate_19

AV:197 data float 197 nvoEcsFlow19 inc count (9) Output (non-polled) 30291/19
E Valve Addr 20
01-Cntl Output Signal boilerstate_20

AV:201 data float 201 nvoEcsState20 inc count (9) Output (non-polled) 30004/20
C.2.6 - Twelve C-Mores, Six ECS/SP, Four Modulex, and Two ACS/BMS II (Cont.)
