background image

Page 25 of 64

USER MANUAL

AERCO/ProtoNode Gateway

OMM-0080_0D

AERCO International, Inc.

• 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288

VD2:011712
1

GF-129

Appendix B. REFERENCE

B.1 Specifications

ProtoNode RER

ProtoNode LER

Electrical
Connections

One 6-pin Phoenix connector, one RS-485
+/- ground port, power +/- frame ground
port
One 3-pin RS-485 Phoenix connector, one
RS-485 +/- ground port
One Ethernet-10/100 Ethernet port

One 6-pin Phoenix connector, one RS-485
+/- ground port, power +/- frame ground
port
One Ethernet 10/100 BaseT port
One FTT-10 LonWorks port

Approvals:

CE (EN55022;EN55024; EN60950), UL916, FCC Class A Part 15, DNP3 Conformance Tested,
OPC Self-tested for Compliance, RoHS Compliant, CSA 205 Approved
BTL Marked

LonMark Certified

Power
Requirements

Multi-mode power adapter: 9-30 VDC, 12-24 VAC

Physical
Dimensions

11.5 cm L x 8.3 cm W x 4.1 cm H (4.5 x 3.2 x 1.6 in.)

Weight:

0.2 kg (0.4 lbs)

Operating
Temperature:

-40°C to 75°C (-40°F to167°F)

Surge Suppression EN61000-4-2 ESD EN61000-4-3 EMC EN61000-4-4 EFT
Humidity:

5 - 90% RH (non-condensing)

(Specifications subject to change without notice)

B.1.1 Compliance with UL Regulations

For UL compliance, the following instructions must be met when operating the ProtoNode.

The units shall be powered by listed LPS or Class 2 power supply suited to the expected operating temperature
range.

The interconnecting power connector and power cable shall:

• Comply with local electrical code.

• Be suited to the expected operating temperature range.

• Meet the current and voltage rating for the ProtoNode/Net

Furthermore, the interconnecting power cable shall:

• not exceed 3.05m (118.3”) in length.
