USER MANUAL
AERCO/ProtoNode Gateway
OMM-0080_0D
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288 VD2:011712
1
GF-129
Equipment Point Name Name
Read
Only BACnet
Type:ID
N2 Type N2 ID
Lon SNVT
NAME
Lon SNVT Lon Direction
ModBus/Unit
Address
Blr Addr 4
01-Fire Rate Out boilerstate_4  AV:31 data float 31 nvoBlrState4 inc count (9) Output (non-polled) 30009/4
02-Active Setpoint effectsetpt_4  AV:32 data float 32 nvoEffSetpt4 inc count (9) Output (non-polled) 30017/4
03-Net Remote Setpt setpt_4 AV:33 data float 33 nviSetpt4 inc count (9) Input (non-polling) 40001/4
05-Fire Rate In boilerload_4  AV:35 data float 35 nvoBlrLoad4 inc count (9) Output (non-polled) 30018/4
06-Outlet Temp localsuptemp_4  AV:36 data float 36
nvoLocSupTmp
4
inc count (9) Output (non-polled) 30003/4
07-Display Code dispcode_4  AV:37 data float 37 nvoDispCode4 inc count (9) Output (non-polled) 30001/4
08-Unit Status unitstat_4  AV:38 data float 38 nvoUnitStat4 inc count (9) Output (non-polled) 30002/4
09-Run Cycles runcycles_4  AV:39 data float 39 nvoRunCycles4 51 Output (non-polled) 30012-30013/4
10-Run Hours runhours_4  AV:40 data float 40 nvoRunHours4 51 Output (non-polled) 30014-30015/4
Blr Addr 5
01-Fire Rate Out boilerstate_5  AV:41 data float 41 nvoBlrState5 inc count (9) Output (non-polled) 30009/5
02-Active Setpoint effectsetpt_5  AV:42 data float 42 nvoEffSetpt5 inc count (9) Output (non-polled) 30017/5
03-Net Remote Setpt setpt_5 AV:43 data float 43 nviSetpt5 inc count (9) Input (non-polling) 40001/5
05-Fire Rate In boilerload_5  AV:45 data float 45 nvoBlrLoad5 inc count (9) Output (non-polled) 30018/5
06-Outlet Temp localsuptemp_5  AV:46 data float 46
nvoLocSupTmp
5
inc count (9) Output (non-polled) 30003/5
07-Display Code dispcode_5  AV:47 data float 47 nvoDispCode5 inc count (9) Output (non-polled) 30001/5
08-Unit Status unitstat_5  AV:48 data float 48 nvoUnitStat5 inc count (9) Output (non-polled) 30002/5
09-Run Cycles runcycles_5  AV:49 data float 49 nvoRunCycles5 51 Output (non-polled) 30012-30013/5
10-Run Hours runhours_5  AV:50 data float 50 nvoRunHours5 51 Output (non-polled) 30014-30015/5
C.2.6 - Twelve C-Mores, Six ECS/SP, Four Modulex, and Two ACS/BMS II (Cont.)
