USER MANUAL
AERCO/ProtoNode Gateway
OMM-0080_0D
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288 VD2:011712
1
GF-129
Equipment Point Name Name
Read
Only BACnet
Type:ID
N2 Type N2 ID
Lon SNVT
NAME
Lon SNVT Lon Direction
ModBus/Unit
Address
11-Error Code errcode_15

AV:148 data float 148
nvoMlxErrCode
15
51 Output (non-polled) 40001/15
08-Unit Status unitstat_15

AV:149 data float 149 nvoMlxStat15 inc count (9) Output (non-polled) 30002/15
09-Ret Flow Temp returntemp_15

AV:150 data float 150
nvoMlxRetTmp
15
inc count (9) Output (non-polled) 41004/15
Mlx Addr 16
01-Act Mod Lev boilerstate_16

AV:151 data float 151 nvoMlxState16 inc count (9) Output (non-polled) 41009/16
02-Target Setpoint effectsetpt_16

AV:152 data float 152 nvoMlxSetpt16 inc count (9) Output (non-polled) 41019/16
03-Req Outlet Temp setpt_16 AV:153 data float 153
nviMlxSetptRq1
6
inc count (9) Input (non-polling) 41005/16
04-Net Direct Drive boilercmd_16 AV:154 data float 154 nviMlxCmd16 inc count (9) Input (non-polling) 40002/16
05-Mod Lev In boilerload_16

AV:155 data float 155 nvoMlxLoad16 inc count (9) Output (non-polled) 41201/16
06-Flow Sens Temp
localsuptemp_1
6 
AV:156 data float 156
nvoMlxSupTmp
16
inc count (9) Output (non-polled) 41003/16
07-Display Code dispcode_16

AV:157 data float 157
nvoMlxDispCod
e16
inc count (9) Output (non-polled) 30001/16
11-Error Code errcode_16

AV:158 data float 158
nvoMlxErrCode
16
51 Output (non-polled) 40001/16
08-Unit Status unitstat_16

AV:159 data float 159 nvoMlxStat16 inc count (9) Output (non-polled) 30002/16
09-Ret Flow Temp returntemp_16

AV:160 data float 160
nvoMlxRetTmp
16
inc count (9) Output (non-polled) 41004/16
E Valve Addr 17
01-Cntl Output Signal boilerstate_17

AV:171 data float 171 nvoEcsState17 inc count (9) Output (non-polled) 30004/17
02-Setpoint effectsetpt_17

AV:172 data float 172 nvoEcsSetpt17 inc count (9) Output (non-polled) 30006/17
03-RmSetpt rmsetpt_17 AV:173 data float 173
nviEcsSetptRq
17
inc count (9) Input (non-polling) 40027/17
04-Outlet Temp
localsuptemp_1
7 
AV:174 data float 174
nvoEcsSupTmp
17
inc count (9) Output (non-polled) 30002/17
05-FBk Sensor Temp
localrettemp_1
7 
AV:175 data float 175
nvoEcsRetTmp
17
inc count (9) Output (non-polled) 30170/17
C.2.6 - Twelve C-Mores, Six ECS/SP, Four Modulex, and Two ACS/BMS II (Cont.)
