1
GF-129
C.2.3 - Twelve C-Mores and One ACS/BMS II/BMS
Equipment
Point Name
Name
Read
Only
BACnet Type:ID
N2 Type
N2 ID
Lon SNVT NAME
Lon SNVT
Lon Direction
ModBus/Unit
Address
Blr Addr 1
01-Fire Rate Out
boilerstate_1
AV:26
data float
1
nvoBlrState1
inc count (9)
Output (non-polled)
30009/1
02-Active Setpoint
effectsetpt_1
AV:27
data float
2
nvoEffSetpt1
inc count (9)
Output (non-polled)
30017/1
03-Net Remote Setpt
setpt_1
AV:24
data float
3
nviSetpt1
inc count (9)
Input (non-polling)
40001/1
05-Fire Rate In
boilerload_1
AV:28
data float
5
nvoBlrLoad1
inc count (9)
Output (non-polled)
30018/1
06-Outlet Temp
localsuptemp_1
AV:29
data float
6
nvoLocSupTmp1
inc count (9)
Output (non-polled)
30003/1
07-Display Code
dispcode_1
AV:22
data float
7
nvoDispCode1
inc count (9)
Output (non-polled)
30001/1
08-Unit Status
unitstat_1
AV:23
data float
8
nvoUnitStat1
inc count (9)
Output (non-polled)
30002/1
09-Run Cycles
runcycles_1
AV:42
data float
9
nvoRunCycles1
51
Output (non-polled)
30012-30013/1
10-Run Hours
runhours_1
AV:43
data float
10
nvoRunHours1
51
Output (non-polled)
30014-30015/1
Blr Addr 2
01-Fire Rate Out
boilerstate_2
AV:30
data float
11
nvoBlrState2
inc count (9)
Output (non-polled)
30009/2
02-Active Setpoint
effectsetpt_2
AV:46
data float
12
nvoEffSetpt2
inc count (9)
Output (non-polled)
30017/2
03-Net Remote Setpt
setpt_2
AV:47
data float
13
nviSetpt2
inc count (9)
Input (non-polling)
40001/2
05-Fire Rate In
boilerload_2
AV:50
data float
15
nvoBlrLoad2
inc count (9)
Output (non-polled)
30018/2
06-Outlet Temp
localsuptemp_2
AV:51
data float
16
nvoLocSupTmp2
inc count (9)
Output (non-polled)
30003/2
07-Display Code
dispcode_2
AV:52
data float
17
nvoDispCode2
inc count (9)
Output (non-polled)
30001/2
08-Unit Status
unitstat_2
AV:53
data float
18
nvoUnitStat2
inc count (9)
Output (non-polled)
30002/2
09-Run Cycles
runcycles_2
AV:44
data float
19
nvoRunCycles2
51
Output (non-polled)
30012-30013/2
10-Run Hours
runhours_2
AV:45
data float
20
nvoRunHours2
51
Output (non-polled)
30014-30015/2
Blr Addr 3
01-Fire Rate Out
boilerstate_3
AV:54
data float
21
nvoBlrState3
inc count (9)
Output (non-polled)
30009/3
02-Active Setpoint
effectsetpt_3
AV:55
data float
22
nvoEffSetpt3
inc count (9)
Output (non-polled)
30017/3
03-Net Remote Setpt
setpt_3
AV:56
data float
23
nviSetpt3
inc count (9)
Input (non-polling)
40001/3
05-Fire Rate In
boilerload_3
AV:60
data float
25
nvoBlrLoad3
inc count (9)
Output (non-polled)
30018/3
06-Outlet Temp
localsuptemp_3
AV:61
data float
26
nvoLocSupTmp3
inc count (9)
Output (non-polled)
30003/3
07-Display Code
dispcode_3
AV:62
data float
27
nvoDispCode3
inc count (9)
Output (non-polled)
30001/3
08-Unit Status
unitstat_3
AV:63
data float
28
nvoUnitStat3
inc count (9)
Output (non-polled)
30002/3
09-Run Cycles
runcycles_3
AV:58
data float
29
nvoRunCycles3
51
Output (non-polled)
30012-30013/3
10-Run Hours
runhours_3
AV:59
data float
30
nvoRunHours3
51
Output (non-polled)
30014-30015/3
