Page 41 of 64

USER MANUAL

AERCO/ProtoNode Gateway

OMM-0080_0D

AERCO International, Inc.

• 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288

VD2:011712
1

GF-129

Equipment

Point Name

Name

Read
Only

BACnet Type:ID

N2 Type

N2 ID

Lon SNVT NAME

Lon SNVT

Lon Direction

ModBus/Unit
Address

Blr Addr 4

01-Fire Rate Out

boilerstate_4



AV:70

data float

31

nvoBlrState4

inc count (9)

Output (non-polled)

30009/4

02-Active Setpoint

effectsetpt_4



AV:71

data float

32

nvoEffSetpt4

inc count (9)

Output (non-polled)

30017/4

03-Net Remote Setpt

setpt_4

AV:72

data float

33

nviSetpt4

inc count (9)

Input (non-polling)

40001/4

05-Fire Rate In

boilerload_4



AV:73

data float

35

nvoBlrLoad4

inc count (9)

Output (non-polled)

30018/4

06-Outlet Temp

localsuptemp_4



AV:65

data float

36

nvoLocSupTmp4

inc count (9)

Output (non-polled)

30003/4

07-Display Code

dispcode_4



AV:66

data float

37

nvoDispCode4

inc count (9)

Output (non-polled)

30001/4

08-Unit Status

unitstat_4



AV:67

data float

38

nvoUnitStat4

inc count (9)

Output (non-polled)

30002/4

09-Run Cycles

runcycles_4



AV:68

data float

39

nvoRunCycles4

51

Output (non-polled)

30012-30013/4

10-Run Hours

runhours_4



AV:69

data float

40

nvoRunHours4

51

Output (non-polled)

30014-30015/4

Blr Addr 5

01-Fire Rate Out

boilerstate_5



AV:80

data float

41

nvoBlrState5

inc count (9)

Output (non-polled)

30009/5

02-Active Setpoint

effectsetpt_5



AV:81

data float

42

nvoEffSetpt5

inc count (9)

Output (non-polled)

30017/5

03-Net Remote Setpt

setpt_5

AV:82

data float

43

nviSetpt5

inc count (9)

Input (non-polling)

40001/5

05-Fire Rate In

boilerload_5



AV:74

data float

45

nvoBlrLoad5

inc count (9)

Output (non-polled)

30018/5

06-Outlet Temp

localsuptemp_5



AV:75

data float

46

nvoLocSupTmp5

inc count (9)

Output (non-polled)

30003/5

07-Display Code

dispcode_5



AV:76

data float

47

nvoDispCode5

inc count (9)

Output (non-polled)

30001/5

08-Unit Status

unitstat_5



AV:77

data float

48

nvoUnitStat5

inc count (9)

Output (non-polled)

30002/5

09-Run Cycles

runcycles_5



AV:78

data float

49

nvoRunCycles5

51

Output (non-polled)

30012-30013/5

10-Run Hours

runhours_5



AV:79

data float

50

nvoRunHours5

51

Output (non-polled)

30014-30015/5

Blr Addr 6

01-Fire Rate Out

boilerstate_6



AV:90

data float

51

nvoBlrState6

inc count (9)

Output (non-polled)

30009/6

02-Active Setpoint

effectsetpt_6



AV:91

data float

52

nvoEffSetpt6

inc count (9)

Output (non-polled)

30017/6

03-Net Remote Setpt

setpt_6

AV:92

data float

53

nviSetpt6

inc count (9)

Input (non-polling)

40001/6

05-Fire Rate In

boilerload_6



AV:84

data float

55

nvoBlrLoad6

inc count (9)

Output (non-polled)

30018/6

06-Outlet Temp

localsuptemp_6



AV:85

data float

56

nvoLocSupTmp6

inc count (9)

Output (non-polled)

30003/6

07-Display Code

dispcode_6



AV:86

data float

57

nvoDispCode6

inc count (9)

Output (non-polled)

30001/6

08-Unit Status

unitstat_6



AV:87

data float

58

nvoUnitStat6

inc count (9)

Output (non-polled)

30002/6

09-Run Cycles

runcycles_6



AV:88

data float

59

nvoRunCycles6

51

Output (non-polled)

30012-30013/6

10-Run Hours

runhours_6



AV:89

data float

60

nvoRunHours6

51

Output (non-polled)

30014-30015/6

C.2.3 - Twelve C-Mores and One ACS/BMS II/BMS (Cont.)
