USER MANUAL
AERCO/ProtoNode Gateway
OMM-0080_0D
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288 VD2:011712
1
GF-129
Equipment Point Name Name
Read
Only
BACnet
Type:ID
N2 Type
N2
ID
Lon SNVT NAME Lon SNVT Lon Direction ModBus/Unit Address
07-Flow Rate flowrate_3

AV:155 data float 21 nvoEcsFlow31
inc count
(9)
Output (non-polled) 30291/31
E Valve Addr 32
01-Cntl Output
Signal
boilerstate_4

AV:10 data float 22 nvoEcsState32
inc count
(9)
Output (non-polled) 30004/32
02-Setpoint effectsetpt_4

AV:158 data float 23 nvoEcsSetpt32
inc count
(9)
Output (non-polled) 30006/32
03-RmSetpt rmsetpt_4 AV:159 data float 24 nviEcsSetptRq32
inc count
(9)
Input (non-polling) 40027/32
04-Outlet Temp localsuptemp_4

AV:160 data float 25 nvoEcsSupTmp32
inc count
(9)
Output (non-polled) 30002/32
05-FBk Sensor
Temp
localrettemp_4

AV:161 data float 26 nvoEcsRetTmp32
inc count
(9)
Output (non-polled) 30290/32
06-Over Temp
Alarm
unitstat_4

AV:156 data float 27 nvoEcsStat32
inc count
(9)
Output (non-polled) 30075/32
07-Flow Rate flowrate_4

AV:157 data float 28 nvoEcsFlow32
inc count
(9)
Output (non-polled) 30291/32
C.2.6 - Twelve C-Mores, Six ECS/SP, Four Modulex and Two ACS/BMS II
Equipment Point Name Name
Read
Only BACnet
Type:ID
N2 Type N2 ID
Lon SNVT
NAME
Lon SNVT Lon Direction
ModBus/Unit
Address
Blr Addr 1
01-Fire Rate Out boilerstate_1

AV:1 data float 1 nvoBlrState1 inc count (9) Output (non-polled) 30009/1
02-Active Setpoint effectsetpt_1

AV:2 data float 2 nvoEffSetpt1 inc count (9) Output (non-polled) 30017/1
03-Net Remote Setpt setpt_1 AV:3 data float 3 nviSetpt1 inc count (9) Input (non-polling) 40001/1
05-Fire Rate In boilerload_1

AV:5 data float 5 nvoBlrLoad1 inc count (9) Output (non-polled) 30018/1
06-Outlet Temp localsuptemp_1

AV:6 data float 6
nvoLocSupTmp
1
inc count (9) Output (non-polled) 30003/1
07-Display Code dispcode_1

AV:7 data float 7 nvoDispCode1 inc count (9) Output (non-polled) 30001/1
08-Unit Status unitstat_1

AV:8 data float 8 nvoUnitStat1 inc count (9) Output (non-polled) 30002/1
09-Run Cycles runcycles_1

AV:9 data float 9 nvoRunCycles1 51 Output (non-polled) 30012-30013/1
10-Run Hours runhours_1

AV:10 data float 10 nvoRunHours1 51 Output (non-polled) 30014-30015/1
C.2.5 – ECS/SP (Cont.)
