12.4 Examples of sending/receiving measurement mode
settings
Example: When "Height (profile compression (time
axis): OFF" is selected and "Average" height is
measured.
These can be summarized as follows:
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:06h, Item:03h
Target1:00h~0Fh (OUT1~16) Target2~4:00h
byte
Setting Data
0
Minimum display unit (from
)
1
Measurement mode (from
)
2
Reserved (fixed as 0)
3
Reserved (fixed as 0)
4
From 4byte, unique parameters
are assigned to each
measurement mode. For details on
the unique parameters, see
[Unique parameters of
measurement mode from 4byte]
~
N
1:Height (when profile compression (time
axis) is off)
byte
Setting Data
4
Measurement target head: 0:
HeadA, 1: HeadB, 2: Combined
profile (only when profile combine
(wide) is on)
5
Measurement target selection: 0:
Peak, 1: Bottom, 2: Knee, 3:
Intsect (lines), 4: Intsect (lin–arc),
5: Center of circle, 6: Average
6
Position correction selection: 0: No
position correction, 1: Position
correction1, 2: Position correction2
7
Reserved (fixed as 0)
8
Unique parameters are assigned
to each measurement target. For
details on the unique parameters,
see "Measurement area details"
~
N
N+1
Reserved (fixed as 0)
~
91
6:Average
byte
Setting Data
0
Area Left: any value in
measurement range
(0.01μm unit Sined 32–bit integer
example: 5mm=500000)
1
2
3
4
Area Right: any value in
measurement range
(0.01μm unit Sined 32–bit integer
example: 5mm=500000)
5
6
7
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:06h, Item:03h
Target1:00h~0Fh (OUT1~16) Target2~4:00h
byte
Setting Data
0
Minimum display unit (from
)
1
Measurement mode (from
)
2
Reserved (fixed as 0)
3
Reserved (fixed as 0)
4
Measurement target head: 0:
HeadA, 1: HeadB, 2: Combined
profile (only when profile combine
(wide) is on)
Measurement
mode
1:Height
5
Measurement target selection: 0:
Peak, 1: Bottom, 2: Knee, 3:
Intsect (lines), 4: Intsect (lin–arc),
5: Center of circle, 6: Average
6
Position correction selection: 0: No
position correction, 1: Position
correction1, 2: Position correction2
7
Reserved (fixed as 0)
8
Area Left: any value in
measurement range
(0.01μm unit Sined 32–bit integer
example: 5mm=500000)
9
10
Measurement
target
6:Average
11
12
Area Right: any value in
measurement range
(0.01μm unit Sined 32–bit integer
example: 5mm=500000)
13
14
15
16
Reserved (fixed as 0)
~
