81 LJ-V7000_COM_RM_E
[Unique parameters of Measuring period from
4byte]
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:06h, Item:06h
Target1:00h~0Fh (OUT1~16) Target2~4:00h
Unique parameters are assigned to each measurement
value filter.
1:Moving average
byte Setting Data
0
Averagecount: 0:4 times, 1:16 times, 2:64 times,
3:256 times, 4:1024 times, 5:4096 times
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
2:Low-pass filter
3:High-pass filter
byte Setting Data
0
Cutoff frequency: 0:0.1Hz, 1:0.3Hz, 2:1Hz, 3:3Hz,
4:10Hz, 5:30Hz, 6:100Hz, 7:300Hz, 8:1000Hz
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:06h, Item:07h (Scaling measurement value1),
08h (Scaling display value1), 09h (Scaling measurement
value2), 0Ah (Scaling display value2)
Target1:00h~0Fh (OUT1~16) Target2~4:00h
byte Setting Data
0 Measurement value/Display value: 0.01μm unit
Sined 32-bit integer.
*Display range lower limit for the minimum display
unit Measurement value/Display value Display
range upper limit for the minimum display unit.
1
2
3
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:06h, Item:0Bh
Target1:00h~0Fh (OUT1~16) Target2~4:00h
byte Setting Data
0
Measuring mode: 0:Normal, 1:Peak hold, 2:bottom
hold, 3:Peak to Peak hold, 4:Average hold, 5:Sample
hold, 6:Peak, 7:bottom, 8:Peak to Peak, 9:Average
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:06h, Item:0Ch
Target1:00h~0Fh (OUT1~16) Target2~4:00h
byte Setting Data
0
Measuring period: 0:Terminal/command,
1:Measurement area 2 :OUT reference,
3:Threshhold (level), 4:Threshhold (Edge)
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
4 Unique parameters are assigned to each
measuring period. The unique parameters are
described below.
~
15
1:Measurement area
byte Setting Data
4
Measure start position: value withinBatch point
5
6
Measure end position: value withinBatch point
7
8
Reserved (fixed as 0) ~
15
2:OUT reference
byte Setting Data
4 Reference OUT: 0:OUT1, 1:OUT2 15:OUT16
5
Reserved (fixed as 0) ~
15
3:Threshold (level)
byte Setting Data
4
Upper limit: 0.01μm unit. Sined 32-bit integer.
*Display range lower limit for the minimum display
unit Upper limit display range upper limit for
the minimum display unit
5
6
7
8
Lower limit: 0.01μm unit. Sined 32-bit integer.
*Display range lower limit for the minimum display
unit Lower limit dislay range upper limit for the
minimum display unit
9
10
11
12
Reserved (fixed as 0)
13
14
15
4:Threshold (Edge)
byte Setting Data
4
Edge threshold: 0.01μm unit. Sined 32-bit integer.
*Display range lower limit for the minimum display
unit Edge threshold display range upper limit
for the minimum display unit
5
6
7
8
Edge direction: 0:Rising, 1:Falling
9 Reserved (fixed as 0)
10 Reserved (fixed as 0)
11 Reserved (fixed as 0)
12
Measurement count:
when batch off:Integer from 1 to 999,999
when batch on:Integer from 1 to Batch point
13
14
15
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:06h, Item:0Dh
Target1:00h~0Fh (OUT1~16) Target2~4:00h
byte Setting Data
0
Offset: 0.01μm unit. Sined 32-bit integer.
*Display range lower limit for the minimum display
unit Offset display range upper limit for the
minimum display unit
1
2
3
