84 LJ-V7000_COM_RM_E
2:Knee
byte Setting Data
0
Area Left: any value in measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
1
2
3
4
Area Right: any value in measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
5
6
7
8
Knee shape: 0:Valley, 1:Peak
9 Detection direction: 0: + direction, 1: - direction
10 Detection No: 1~10
11 Sensitivity: 0~100
3:Intersection (lines)
byte Setting Data
0
Linear calculation area: 0: Area2
disabled, 1: Area2 enabled
Line1
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
4
Line calculation area Left: Any
value in measurement range
(0.01μm unit Sined 32-bit integer.
example: 5mm=500000)
5
6
7
8
Line calculation area Right: Any
value in measurement range
(0.01μm unit Sined 32-bit integer.
example: 5mm=500000)
9
10
11
12
Area2 Left: Any value in
measurement range (0.01μm unit
Sined 32-bit integer.
example: 5mm=500000)
13
14
15
16
Area2 Right: Any value in
measurement range (0.01μm unit
Sined 32-bit integer.
example: 5mm=500000)
17
18
19
20
Linear calculation area count: 0:
Area2 disabled, 1: Area2 enabled
Line2
21 Reserved (fixed as 0)
22 Reserved (fixed as 0)
23 Reserved (fixed as 0)
24
Line calculation area Left: Any
value in measurement range
(0.01μm unit Sined 32-bit integer.
example: 5mm=500000)
25
26
27
28
Line calculation area Right: Any
value in measurement range
(0.01μm unit Sined 32-bit integer.
example: 5mm=500000)
29
30
31
32
Area2 Left: Any value in
measurement range (0.01μm unit
Sined 32-bit integer.
example: 5mm=500000)
33
34
35
36
Area2 Right: Any value in
measurement range (0.01μm unit
Sined 32-bit integer.
example: 5mm=500000)
37
38
39
4:Contact (line-arc)
byte Setting Data
Linear calculation area: 0: Area2
disabled, 1: Area2 enabled
Line
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
4
Line calculation area Left: Any
value in measurement range
(0.01μm unit Sined 32-bit integer.
example: 5mm=500000)
5
6
7
8
Line calculation area Right: Any
value in measurement range
(0.01μm unit Sined 32-bit integer.
example: 5mm=500000)
9
10
11
12
Area2 Left: Any value in
measurement range (0.01μm unit
Sined 32-bit integer.
example: 5mm=500000)
13
14
15
16
Area2 Right: Any value in
measurement range (0.01μm unit
Sined 32-bit integer.
example: 5mm=500000)
17
18
19
20
Arc calculation area: 0: Area2
disabled, 1: Area2 enabled
Arc
21 Reserved (fixed as 0)
22 Reserved (fixed as 0)
23 Reserved (fixed as 0)
24
Arc calculation area Left: Any
value in measurement range
(0.01μm unit Sined 32-bit integer.
example: 5mm=500000)
25
26
27
28
Arc calculation area Right: Any
value in measurement range
(0.01μm unit Sined 32-bit integer.
example: 5mm=500000)
29
30
31
32
Area2 Left: Any value in
measurement range (0.01μm unit
Sined 32-bit integer.
example: 5mm=500000)
33
34
35
36
Area2 Right: Any value in
measurement range (0.01μm unit
Sined 32-bit integer.
example: 5mm=500000)
37
38
39
