38 LJ-V7000_COM_RM_E
 Get batch profiles (operation mode "high-speed (profile only)")
Format
LONG LJV7IF_GetBatchProfile(LONG lDeviceId,
LJV7IF_GET_BATCH_PROFILE_REQ* pReq,
LJV7IF_GET_BATCH_PROFILE_RSP* pRsp, LJV7IF_PROFILE_INFO *
pProfileInfo, DWORD* pdwBatchData, DWORD dwDataSize);
Parameters
lDeviceId(in)
Specifies the communication device to communicate with.
pReq(in)
Specifies the position, etc., of the profiles to get.
For each member, see "8 Constant, Structure Definitions".
pRsp(out)
Indicates the position, etc., of the profiles that were actually acquired.
For each member, see "8 Constant, Structure Definitions".
pProfileInfo(out)
The profile information for the acquired profiles.
For each member, see "8 Constant, Structure Definitions".
pdwBatchData(out)
The buffer to get the profile data.
The profile data is stored in this buffer with "LJV7IF_PROFILE_HEADER -
signed 32-bit profile data - LJV7IF_PROFILE_FOOTER" as a single unit of
profile data, and only the number of profiles that could be acquired are
returned.
dwDataSize(in)
pdwProfileData size in BYTEs
Return value
0x8080: The operation mode is "advanced (with OUT measurement)"
0x8081: Not "batch measurements on and profile compression (time axis) off"
0x80A0: No batch data (batch measurements not run even once)
Explanation
This function gets profile data.
Profile data is stored in 0.01 μm units.
For the details on the data stored in the profile data (storage order and size), see
"9.2.9 Supplement".
To read all of the profiles in one batch, read them with the procedure below.
1. Call this function by specifying LJV7IF_BATCH_POS_CURRENT for
byPosMode in pReq. Save the start position and the amount of profiles that
were read and the batch number that was read.
2. Configure pReq as listed below and call this function again.
byPosMode = LJV7IF_BATCH_POS_SPEC
dwGetBatchNo = batch number that was read
byGetProfNo = starting profile number of the unread profiles in the batch
3. Update dwGetProfNo in step 2 and call this function until all of the profiles in
the batch can be read.
Supported version 1.00
