11.2 Save file format
This section describes the file format for profiles that are saved in the get profile process.
• File format: TSV (tab separated text file)
• Values: The values acquired with the get profile interface are saved unmodified.
• Units: See "9.2.6 Acquiring measurement results".
 Image of the arrangement of data in the save file when "Save the measurement" in
the [DLL functions] Simple function sample tab is clicked
* 2 files are created. The second file contains internal measurement values (Measurements for the profile.
Measurements taken immediately before measuring mode processing). When using GetMeasurement-
Value the second file is empty as only measurement values are acquired.
 Image of the arrangement of data in the save file when "Save the profile" in the
[DLL functions] Simple function sample tab is clicked (2 heads, compression (time
axis) on)
Output file
OUT1 measurement value OUT2 measurement value OUT16 measurement value
Output file
X
coordinates Max. profiles for
head A Min. profiles for
head A Max. profiles for
head B Min. profiles for
head B
Profile data
