KEYENCE LJ-V7000 Series User Manual
Page 54
54
LJ-V7000_COM_RM_E
9.2.9.8 Specific examples
(i) For configuration 1 (initial settings)
Heads: 2
Measurement range X direction: Full
Binning: Off
Wide: Off
Compression (X axis): Off
Compression (time axis): Off
The amount of profile data is 800
The profile data storage order is as follows. (See profile data storage order for 1)
1. Head A profiles (800)
3. Head B profiles (800)
When getting 10 profiles with LJV7IF_GetProfile, the data below is stored in pdwProfileData.
Profile 1
LJV7IF_PROFILE_HEADER
32bit×6
1. Head A profiles (800)
32bit×800
3. Head B profiles (800)
32bit×800
LJV7IF_PROFILE_FOOTER
32bit×1
.
.
.
Profile 10
LJV7IF_PROFILE_HEADER
32bit×6
1. Head A profiles (800)
32bit×800
3. Head B profiles (800)
32bit×800
LJV7IF_PROFILE_FOOTER
32bit×1
