KEYENCE LJ-V7000 Series - Manual (Page 19)

19 LJ-V7000_COM_RM_E
Name Storage information structure
Definition
Typedef struct {
BYTE byStatus;
BYTE byProgramNo;
BYTE byTarget;
BYTE reserve[5];
DWORD dwStorageCnt;
} LJV7IF_ STORAGE_INFO;
Description
Information related to the storage status.
byStatus
Storage status.
0: Empty (Takes on this value when the target surface has not operated even once in a
program with storage on)
1: Storing (only the active storage surface can be 1)
2: Storage
complete
byProgramNo
The program number for the relevant storage surface.
byTarget
Storage target.0: Data storage, 2: profile storage, 3: batch profile storage.
However, when batch measurements are on and profile compression (time axis) is on, 2:
profile storage is stored.
dwStorageCnt
Storage count (batch count when batch is on)
Comment
For details about "Storage surface", refer to "9.2.9.2.2 For operation mode: advanced (with
OUT measurement)".
Name Get storage data request structure
Definition
Typedef struct {
BYTE reserve[4];
DWORD
dwSurface;
DWORD dwStartNo;
DWORD dwDataCnt;
} LJV7IF_GET_STORAGE_REQ;
Description
The get data designation information in the get data storage data command and the get
profile storage data command.
dwSurface
Storage surface to read.
dwStartNo
The data number to start reading.
dwDataCnt
The number of items to read.
Comment
For details about "Storage surface", refer to "9.2.9.2.2 For operation mode: advanced (with
OUT measurement)".
