KEYENCE LJ-V7000 Series - Manual (Page 68)

68 LJ-V7000_COM_RM_E
• Imaging settings
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:00h, Item:06h
Target1~4:00h
byte Setting Data
0 Mutual interference prevention: 0:OFF, 1:ON
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:00h, Item:07h
Target1~4:00h
byte Setting Data
0
Encoder trigger input mode: 0: 1-phase 1TM (no
dir_), 1:2-phase 1 times, 2:2-phase 2 times,
3:2-phase 4 times
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:00h, Item:08h
Target1~4:00h
byte Setting Data
0
Encoder trigger skipping: 0: Skipping OFF,
1:Skipping ON
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:00h, Item:09h
Target1~4:00h
byte Setting Data
0
Encoder trigger skipping count: 2~1000
1
2
Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:00h, Item:0Ah
Target1~4:00h
byte Setting Data
0
Batch count: 50~15000
1
2
Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:01h, Item:01h
Target1:00h (headA/wide), 01h (headB), Target2~4:00h
byte Setting Data
0 Binning: 0: OFF, 1: ON
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:01h, Item:02h
Target1:00h (headA/wide), 01h (headB), Target2~4:00h
byte Setting Data
0
Measurement range X direction: 0:FULL,
1:MIDDLE, 2:SMALL
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:01h, Item:03h
Target1:00h (headA/wide), 01h (headB), Target2~4:00h
byte Setting Data
0
Measurement range Z direction: 0:FULL,
1:MIDDLE, 2:SMALL
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:01h, Item:05h
Target1:00h (headA/wide), 01h (headB), Target2~4:00h
byte Setting Data
0
CMOS sensitivity characteristics: 0:High precision,
1:High dynamic range1, 2:High dynamic range2,
3:High dynamic range3
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:01h, Item:06h
Target1:00h (headA/wide), 01h (headB), Target2~4:00h
byte Setting Data
0
Exposure time: 0:15μs, 1:30μs, 2:60μs, 3:120μs,
4:240μs, 5:480μs, 6:960μs, 7:1920μs, 8:5ms,
9:10ms
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
