KEYENCE LJ-V7000 Series - Manual (Page 69)

69 LJ-V7000_COM_RM_E
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:01h, Item:07h
Target1:00h (headA/wide), 01h (headB), Target2~4:00h
byte Setting Data
0
Imaging mode: 0:standard, 1:multi emission
(synthesis), 2:multi emission (optimized light
intensity)
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:01h, Item:08h
Target1:00h (headA/wide), 01h (headB), Target2~4:00h
byte Setting Data
0 Emission times: 0:2 times, 1:4 times
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:01h, Item:09h
Target1:00h (headA/wide), 01h (headB), Target2~4:00h
byte Setting Data
0 Emission times: 0:3 times, 1:5 times
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:01h, Item:0Ah
Target1:00h (headA/wide), 01h (headB)
Target1:00h (headA/wide), 01h (headB), Target2~4:00h
byte Setting Data
0
Enabled/disabled: 0:Mask disabled, 1:Rectangle,
2:Triangle
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
4
X coordinate1: 1~639
5
6
Z coordinate1: 0~479
7
8
X coordinate2: 1~639
9
10
Z coordinate2: 0~479
11
12
X coordinate3: 2~640 (invalid when Rectangle)
13
14
Z coordinate3: 2~480 (invalid when Rectangle)
15
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:01h, Item:0Bh
Target1:00h (headA/wide), 01h (headB), Target2~4:00h
byte Setting Data
0 Control mode: 0:AUTO, 1:MANUAL
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:01h, Item:0Ch (upper limit value), 0Dh (lower limit
value)
Target1:00h (headA/wide), 01h (headB), Target2~4:00h
byte Setting Data
0 FB upper/lower limit value: 1~99
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:01h, Item:0Eh
Target1:00h (headA/wide), 01h (headB), Target2~4:00h
byte Setting Data
0
FB target area start: 0~639
1
2
FB target area end: 0~639
3
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:01h, Item:0Fh
Target1:00h (headA/wide), 01h (headB), Target2~4:00h
byte Setting Data
0 Peak detection level: 1~5
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:01h, Item:10h
Target1:00h (headA/wide), 01h (headB), Target2~4:00h
byte Setting Data
0 Invalid data interpolation count: 0~255
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
