[Unique parameters of measurement mode from
4byte]
Measurement mode 0:OFF
byte
Setting Data
4
Reserved (fixed as 0)
~
91
1:Height (when profile compression (time axis) is off)
byte
Setting Data
4
Measurement target head: 0: HeadA, 1: HeadB, 2:
Combined profile (only when profile combine
(wide) is on)
5
Measurement target selection: 0: Peak, 1: Bottom,
2: Knee, 3: Intsect (lines), 4: Intsect (lin-arc), 5:
Center of circle, 6: Average
6
Position correction selection: 0: No position
correction, 1: Position correction1, 2: Position
correction2
7
Reserved (fixed as 0)
8
Unique parameters are assigned to each
measurement target. For details on the unique
parameters, see "Measurement area details"
~
N
N+1
Reserved (fixed as 0)
~
91
2:Step
byte
Setting Data
4
Measurement target head: 0: HeadA, 1: HeadB, 2:
Combined profile (only when profile combine
(wide) is on)
5
Measurement target selection: 0: Peak, 1: Bottom,
2: Knee, 3: Intsect (lines), 4: Intsect (lin-arc), 5:
Center of circle, 6: Average
6
Position correction selection: 0: No position
correction, 1: Position correction1, 2: Position
correction2
7
Reserved (fixed as 0)
8
Unique parameters are assigned to each
measurement target. For details on the unique
parameters, see "Measurement area details"
~
M
M+1
Reserved (fixed as 0)
~
47
48
Reference target head: 0: HeadA, 1: HeadB, 2:
Combined profile (only when profile combine
(wide) is on)
49
Referene target selection: 0:Peak, 1:Bottom,
2:Knee, 3:Intsect (lines), 4:Contact (lin-arc), 5:
Center of circle, 6: Average
50
Position correction selection: 0: No position
correction, 1: Position correction1, 2: Position
correction2
51
Reserved (fixed as 0)
52
Unique parameters are assigned to each
Reference target. For details on the unique
parameters, see "Measurement area details"
~
N
N+1
Reserved (fixed as 0)
~
91
3:Position (when profile compression (time axis) is off)
byte
Setting Data
4
Measurement target head: 0: HeadA, 1: HeadB, 2:
Combined profile (only when profile combine (wide) is on)
5
Measurement target selection: 0:Peak, 1:Bottom,
2:Knee, 3:Intsect (lines), 4:Contact (lin-arc),
5:Center of circle, 7:Edge
6
Position correction selection: 0: No position correction,
1: Position correction1, 2: Position correction2
7
Reserved (fixed as 0)
8
Unique parameters are assigned to each
measurement target. For details on the unique
parameters, see "Measurement area details"
~
N
N+1
Reserved (fixed as 0)
~
91
4:Center position, 5:Width
byte
Setting Data
4
Measurement target head: 0: HeadA, 1: HeadB, 2:
Combined profile (only when profile combine (wide) is on)
5
Measurement target selection: 0:Peak, 1:Bottom,
2:Knee, 3:Intsect (lines), 4:Contact (lin-arc),
5:Center of circle 7:Edge
6
Position correction selection: 0: No position correction,
1: Position correction1, 2: Position correction2
7
Reserved (fixed as 0)
8
Unique parameters are assigned to each
measurement target. For details on the unique
parameters, see "Measurement area details"
~
M
M+1
Reserved (fixed as 0)
~
47
48
Reference target selection: 0: HeadA, 1: HeadB, 2:
Combined profile (only when profile combine (wide) is on)
49
Reference target selection: 0:Peak, 1:Bottom,
2:Knee, 3:Intsect (lines), 4:Contact (lin-arc),
5:Center of circle, 7:Edge
50
Position correction selection: 0: No position correction,
1: Position correction1, 2: Position correction2
51
Reserved (fixed as 0)
52
Unique parameters are assigned to each
Reference target. For details on the unique
parameters, see "Measurement area details"
~
N
N+1
Reserved (fixed as 0)
~
91
6:Thickness
byte
Setting Data
4
Measurement target selection: 8:Max thickness,
9:Min thickness, 10:Ave thickness, 11:Max
thickness position, 12:Min thickness position
5
Position correction selection (HeadA): 0: No position
correction, 1: Position correction1, 2: Position correction2
6
Position correction selection (HeadB): 0: No position
correction, 1: Position correction1, 2: Position correction2
7
Reserved (fixed as 0)
8
Unique parameters are assigned to each
measurement target. For details on the unique
parameters, see "Measurement area details"
~
N
N+1
Reserved (fixed as 0)
~
