77 LJ-V7000_COM_RM_E
7:Angle
byte Setting Data
4
Measurement target head: 0: HeadA, 1: HeadB, 2:
Combined profile (only when profile combine
(wide) is on)
5
Measurement reference selection: 0:Angle from
X-axis, 1:Angle between lines
6 Angle range: 0:0~180deg, 1:-90~90deg
7
Measurement target position correction: 0: No
position correction, 1: Position correction1, 2:
Position correction2
8
Reference target position correction: 0: No
position correction, 1: Position correction1, 2:
Position correction2
9 Reserved (fixed as 0)
10 Reserved (fixed as 0)
11 Reserved (fixed as 0)
12
Measurement target Linear calculation area:
0:Area2 disabled, 1:Area2enabled
13 Reserved (fixed as 0)
14 Reserved (fixed as 0)
15 Reserved (fixed as 0)
16
Measurement target Linear calculation area Left:
any value in measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
17
18
19
20
Measurement target Linear calculation area Right:
any value in measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
21
22
23
24
Measurement target Linear calculation area2 Left:
any value in measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
25
26
27
28
Measurement target Linear calculation area2
Right: any value in measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
29
30
31
32
Reference target Linear calculation area: 0:Area2
disabled, 1:Area2 enabled
33 Reserved (fixed as 0)
34 Reserved (fixed as 0)
35 Reserved (fixed as 0)
36
Reference target Linear calculation area Left: any
value in measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
37
38
39
40
Reference target Linear calculation area Right: any
value in measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
41
42
43
44
Reference target Linear calculation area2 Left: any
value in measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
45
46
47
48
Reference target Linear calculation area2 Right:
any value in measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
49
50
51
52
Reserved (fixed as 0) ~
91
8:R measurement
byte Setting Data
4
Measurement target head: 0: HeadA, 1: HeadB, 2:
Combined profile (only when profile combine
(wide) is on)
5
Position correction selection: 0: No position
correction, 1: Position correction1, 2: Position
correction2
6 Reserved (fixed as 0)
7 Reserved (fixed as 0)
8
Arc calculation area: 0: Area2 disabled, 1: Area2
enabled
9 Reserved (fixed as 0)
10 Reserved (fixed as 0)
11 Reserved (fixed as 0)
12
Arc calculation area Left: any value in
measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
13
14
15
16
Arc calculation area Right: any value in
measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
17
18
19
20
Arc calculation area2 Left: any value in
measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
21
22
23
24
Arc calculation area2 Right: any value in
measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
25
26
27
28
Reserved (fixed as 0) ~
91
