12:Distance (point-line)
byte
Setting Data
4
Measurement target head: 0: HeadA, 1: HeadB, 2:
Combined profile (only when profile combine (wide) is on)
5
Measurement target selection: 0:Peak, 1:Bottom, 2:Knee,
3:Intsect (lines), 4:Contact (lin-arc), 5:Center of circle
6
Position correction selection: 0: No position correction,
1: Position correction1, 2: Position correction2
7
Reserved (fixed as 0)
8
Unique parameters are assigned to each
measurement target. For details on the unique
parameters, see "Measurement area details"
~
M
M+1
Reserved (fixed as 0)
~
47
48
Reference target selection: 0: HeadA, 1: HeadB, 2:
Combined profile (only when profile combine
(wide) is on)
49
Position correction selection: 0: No position
correction, 1: Position correction1, 2: Position
correction2
50
Reserved (fixed as 0)
51
Reserved (fixed as 0)
52
Linear calculation area: 0: Area2 disabled, 1:
Area2 enabled
53
Reserved (fixed as 0)
54
Reserved (fixed as 0)
55
Reserved (fixed as 0)
56
Linear calculation area Left: any value in
measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
57
58
59
60
Linear calculation area Right: any value in
measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
61
62
63
64
Area2 Left: any value in measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
65
66
67
68
Area2 Right: any value in measurement range
(0.01μm unit Sined 32-bit integer
example: 5mm=500000)
69
70
71
72
Reserved (fixed as 0)
~
91
13:Height (when profile compression (time axis) is on)
byte
Setting Data
4
Measurement target head: 0: HeadA, 1: HeadB, 2:
Combined profile (only when profile combine
(wide) is on)
5
Measurement target selection: 0:Peak, 1:bottom,
13:Middle value
6
Reserved (fixed as 0)
7
Reserved (fixed as 0)
8
Unique parameters are assigned to each
measurement target. For details on the unique
parameters, see "Measurement area details"
~
N
N+1
Reserved (fixed as 0)
~
91
14:Position (when profile compression (time axis) is on)
byte
Setting Data
4
Measurement target head: 0: HeadA, 1: HeadB, 2:
Combined profile (only when profile combine
(wide) is on)
5
Measurement target selection: 0:Peak, 1:bottom,
7:Edge
6
Reserved (fixed as 0)
7
Reserved (fixed as 0)
8
Unique parameters are assigned to each
measurement target. For details on the unique
parameters, see "Measurement area details"
~
N
N+1
Reserved (fixed as 0)
~
91
15:Deflection width (when profile compression (time axis)
is on)
byte
Setting Data
4
Measurement target head: 0: HeadA, 1: HeadB, 2:
Combined profile (only when profile combine
(wide) is on)
5
Measurement target selection: 14:P-P(Z), 15:P-
P(X)
6
Reserved (fixed as 0)
7
Reserved (fixed as 0)
8
Unique parameters are assigned to each
measurement target. For details on the unique
parameters, see "Measurement area details"
~
N
N+1
Reserved (fixed as 0)
~
91
16:Height (simple 3D)
byte
Setting Data
4
Measurement target head: 0: HeadA, 1: HeadB, 2:
Combined profile (only when profile combine
(wide) is on)
5
Measurement target
selection:0:Peak,1:bottom,6:Average,16:P-P
6
Reserved (fixed as 0)
7
Reserved (fixed as 0)
8
Unique parameters are assigned to each
measurement target. For details on the unique
parameters, see "Measurement area details"
~
M
M+1
Reserved (fixed as 0)
~
15
16
Ycoordinate start position: value within Batch point
17
18
Ycoordinate endposition: value within Batch point
19
20
Reserved (fixed as 0)
~
91
