67 LJ-V7000_COM_RM_E
Change Program setting
• Trigger settings
Type:02h, Category:00h, Item:03h
Target1~4:00h
byte Setting Data
0 Parallel imaging: 0:Disabled, 1:Enabled
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:02h, Category:00h, Item:04h
Target1~4:00h
byte Setting Data
0
Strobe output time: 0:10μs, 1:20μs, 2:50μs,
3:100μs, 4:200μs, 5:500μs, 6:1ms, 7:2ms, 8:5ms,
9:10ms, 10:20ms
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:02h, Category:00h, Item:06h
Target1~4:00h
byte Setting Data
0
Constant when TRG input terminal: 0:7μs, 1:10μs,
2:20μs, 3:50μs, 4:100μs, 5:200μs, 6:500μs, 7:1ms
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:02h, Category:00h, Item:07h
Target1~4:00h
byte Setting Data
0
Constant when ENCODER input terminal: 0:120ns,
1:150ns, 2:250ns, 3:500ns, 4:1μs, 5:2μs, 6:5μs,
7:10μs, 8:20μs
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:02h, Category:00h, Item:08h
Target1~4:00h
byte Setting Data
0
Control terminal minimum input time: 0:250μs,
1:1ms
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:02h, Category:00h, Item:09h
Target1~4:00h
byte Setting Data
0 Change program: 0:Terminal, 1:Command
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:00h, Item:01h
Target1~4:00h
byte Setting Data
0
Trigger mode: 0:Continuous trigger, 1:External
trigger, 2:Encoder trigger
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:00h, Item:02h
Target1~4:00h
byte Setting Data
0
Sampling frequency: 0:10Hz, 1:20Hz, 2:50Hz,
3:100Hz, 4:200Hz, 5:500Hz, 6:1KHz, 7:2KHz,
8:4KHz, 9:4.13KHz, 10:8KHz, 11:16KHz,
12:32KHz, 13:64KHz
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:00h, Item:03h
Target1~4:00h
byte Setting Data
0 Batch measurement: 0:Batch OFF, 1:Batch ON
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:00h, Item:04h
Target1~4:00h
byte Setting Data
0 Inter-trigger pitch: 0:Pitch OFF, 1:Pitch ON
1 Reserved (fixed as 0)
2 Reserved (fixed as 0)
3 Reserved (fixed as 0)
Type:10h~1Fh (10h:Program NO.0, 11h:Program NO.1,
, 1F:Program NO.15)
Category:00h, Item:05h
Target1~4:00h
byte Setting Data
0 Pitch count: 1~50000 (0.001mm unit,
0.001~50.000mm) 1
2
Reserved (fixed as 0)
3 Reserved (fixed as 0)
