3
Contents
7.2.1 Align transmitter and receiver 7-2
7.2.1.1 Prepare for alignment 7-2
7.2.1.2 Adjustment templates 7-2
7.2.1.3 Adjustment directions of transmitter and
receiver 7-3
7.2.1.4 Align transmitter 7-5
7.2.1.5 Tool shapes 7-6
7.2.1.6 Align receiver 7-7
7.2.2 Adjustment template with bracket 7-11
7.3 Adjustment during tool change 7-13
7.3.1 Prepare for adjustment during tool change 7-13
7.3.2 Tool detection 7-13
7.3.3 Make adjustment during tool change 7-16
7.4 Enter overrun 7-19
7.5 Check protective equipment 7-21
7.5.1 Function test of the safety device 7-21
7.5.1.1 Test during initial commissioning 7-21
7.5.1.2 Test after machine modification 7-22
7.5.1.3 Regular inspection 7-22
7.5.1.4 Prepare for function test 7-23
7.5.1.5 Function test using the test piece 7-23
7.5.2 Visual inspection 7-25
Chapter 8 Operation
8.1
Safety guidelines 8-1
8.2 Operating notes 8-2
8.2.1 Switch on PSENvip 8-2
8.2.2 Muting lamp 8-2
8.2.3 Initial press stroke 8-3
8.2.4 Acknowledge protected field modes 8-3
8.2.5 Tool change 8-4
8.2.6 Error messages 8-4
8.2.7 Cleaning the front lenses 8-5
Chapter 9 Diagnostics and Troubleshooting
9.1
Troubleshooting 9-2
9.1.1 Minor errors 9-2
9.1.2 Major errors 9-2
9.1.3 Fatal Error 9-3
9.2 Error messages 9-4
9.3 DIAGNOSTICS menu 9-6
9.3.1 Diagnostic blocks and diagnostic data 9-6
Chapter 10 System Connections
10.1
Overview 10-1
