SAE-1111/1112/1162 Carbon Monoxide (CO) Detectors

7

Installation Guide

Press

ReCal Md Time = 1yr

This is used to set the CO sensor recalibration in-

terval. Use the key to set the ReCal mode

timer to 1, 2, or 3 years. The default is 1 year.

Press to save the setting. (This item is not

shown if the ReCal mode is disabled.)

Press

Alarm Md = Auto

Use the key to set the Alarm Mode to

Auto or Manual. The factory default is Auto. This

setting controls how the relay alarms and the buzz-

er alarm resets back to Normal mode. For the Auto

setting, the device will reset the alarms automati-

cally once the CO level drops below the set alarm

thresholds. For the Manual setting, the CO level

must be below the alarm thresholds AND the user

must press the TEST switch to reset the alarms.

Press to save the setting.

Press

0 Filter = Enable

Use the key to enable or disable the zero

filter. When enabled, the device will filter low ppm

readings, such that 0 to 5 ppm CO will display and

output 0 ppm. When disabled, 0–5 ppm will dis-

play and output actual 0–5 ppm. Press to

save the setting. The factory default is Enable. This

should be set to Disable when doing a ZERO

gas calibration.

Press

Display = CO Value

Use the key to toggle the setting to either

CO Value or Status. When set to CO Value, the

actual ppm value of the CO reading will be dis-

played on the LCD. When set to Status, the ppm

value will not be displayed but only “CO Detector”

or the device operating status (e.g., Test). Press

to save the setting. The factory default is

CO Value.

Press

BackLite = Enable

Use the key to enable or disable the

LCD backlight. The backlight is always on when

enabled and always off when disabled. Press

to save the setting. The factory default is

Enable.

Press

Out Type = 0–5 VDC

Use the key to toggle the voltage out-

put type to either 0–5 VDC or 0–10 VDC. Press

to save the setting. The factory default is

0–5 VDC. This item is only shown if the board’s

output switch is in the VOLT position. The

output type can only be changed by temporarily

disconnecting power to the unit.

Press

Output Test = OFF

This can be used to test the output signal. Use the

key to scroll through the available op-

tions. The analog output and display depends on

the output type configuration.

• For 4–20 mA output, the setting options are

OFF/4/8/12/16/20 mA.

• For 0–5 VDC output, options are

OFF/0/1/2/3/4/5 VDC.

• For 0–10 VDC output, options are

OFF/2/4/6/8/10 VDC.
