SAE-1111/1112/1162 Carbon Monoxide (CO) Detectors 6 Installation Guide
Press
Relay 2 Hyst = 20
Use the key to scroll through the avail-
able options. The Relay 2 hysteresis (deadband)
may be set from 10 to 100 ppm in 5 ppm incre-
ments. Press to save the setting. The
factory default is 20 ppm. Note that the maximum
value may be limited by the trip-point value. (This
item will not be shown if Relay 2 is not installed.)
Press
Relay 2 Del = 2Min
Use the key to scroll through the avail-
able options. The Relay 2 delay may be set from
0 to 10 minutes in 1 minute increments. Press
to save the setting. The factory default is
2 minutes. (This item will not be shown if Relay 2
is not installed.)
Press
Relay 2 Test = OFF
Use the key to enable Relay 2 (ON) dur-
ing test mode or disable it (OFF). Press
to save the setting. The factory default is Off. (This
item will not be shown if Relay 2 is not installed.)
Press
TestMode = Disable
Use the key to disable or enable the
test mode. The factory default is Disable. When
disabled, the TEST button or TEST input will not
initiate the test function. When enabled, pressing
the TEST button or shorting the TEST input will
initiate the test function. Press to save the
setting.
Press
TestMode = Time 5
Use the key to scroll through the avail-
able options. The test mode operating time may be
set from 1 to 15 minutes in 1 minute increments.
Press to save the setting. The factory
default is 5 minutes. This item sets how long the
test mode will operate when the TEST button is
pressed. (This item is not shown if the test mode is
disabled.)
Press
Fault Md = Disable
Use the key to select Enable, Disable, or
Reset. When disabled, the device will not sound
the buzzer or provide LCD and status LED in-
dication when the sensor life is exceeded. When
enabled, the fault alarm will activate to indicate the
sensor life is exceeded. Press to save the
setting. The factory default is Disable. If it is set to
Reset and is pressed, then the fault condi-
tion is cleared, the life-time timer is reset and fault
mode is set back to its default (Disable). It may be
enabled again.
WARNING
All commercial CO sensors have a finite life. The
life expectancy of these models is 5 to 7 years.
They must be replaced periodically to ensure
reliable operation in detecting conditions that are
potentially hazardous to human health and safety.
Press
Fault Md Time = 3yr
Use the key to set the fault mode timer
to 3, 4, 5, or 6 years. The factory default is 3 years.
Press to save the setting. If the desired
time has already been exceeded, then it cannot be
selected. (This item is not shown if the fault mode
is disabled.)
Press
ReCal Md = Enable
Use the key to select Enable, Disable, or
Reset. When disabled, the device will not sound
the buzzer or provide LCD and status LED indica-
tion when the sensor requires recalibration. When
enabled, the ReCal alarm will activate to indicate
the sensor requires recalibration. Press
to save the setting. The factory default is Enable.
If set to Reset and is pressed, then the
ReCal condition is cleared, the ReCal timer is
reset, and ReCal mode is set back to its default
(enabled). This can be used if the CO sensor is
required to be recalibrated at known intervals.
